- AVAILABLE FOR PURCHASE:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 271
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- REQUIRED (NOT INCLUDED):
- 2 30 WATT 12 WATT CONNECTOR PIN LED MODULE BULBS
- OPTION:
- ENERGY EFFICIENT
- OPTION1:
- LED
- OPTION2:
- OUTDOOR
- FAMILY:
- TORCHAIRE 52
- GLASS:
- OPAL FROSTED
- VOLTAGE:
- 120 V
- NUMBER OF BULBS:
- 1
- AIR FLOW CFM:
- 5630
- AIR FLOW EFFICIENCY:
- 181
- BLADE PITCH:
- 14
- BLADE SPAN:
- 52
- BULB TYPE:
- LED MODULE
- CANOPY:
- 5.91 DIA X 2.51 H
- HARMONIZED CODES:
- 8414.51.3000
- KELVIN:
- 2700/3000/3500/4000/5000
- LIGHT KIT INCLUDED:
- YES
- LUMENS / LIGHT OUTPUT:
- 2700
- MOTOR SIZE:
- 126 X 10
- MOTOR TYPE:
- DC
- SHIP CARTON HEIGHT:
- 11.02''
- SHIP CARTON LENGTH:
- 28.58
- SHIP CARTON WIDTH:
- 13.43''
- SOLD BY:
- EACH
- WARRANTY:
- 1 YEAR
- WEIGHT:
- 15.88
- More Info {1}:
- CONTROL: INCLUDES A TR361 HAND-HELD REMOTE
- More Info {2}:
- INSTALLATION: MOUNTS TO FLAT OR MINIMALLY SLOPED CEILINGS WITH THE INCLUDED 1-IN DIAMETER X 6-IN LENGTH DOWNROD - OPTIONAL DOWNRODS ARE AVAILABLE IN LENGTHS UP TO 72 INCHES TO ADJUST THE FANS HEIGHT TO 7FT - 9FT FROM THE FLOOR ENSURING MA..''.
- More Info {3}:
- LIGHTING: INCLUDES DIMMABLE 12-WATT 5CCT LED UPLIGHT AND 30-WATT 5CCT DOWNLIGHT LIGHT KITS WITH OPAL FROSTED GLASS
- More Info {4}:
- LOCATION: DAMP RATED FOR USE IN INDOOR AND OUTDOOR COVERED SPACES EXPOSED TO MOISTURE AND HUMIDITY
- More Info {5}:
- POWER: THE 6-SPEED QUIET AND ENERGY EFFICIENT DC MOTOR PROVIDES AIRFLOW UP TO 5630 CFM
- More Info {6}:
- SAVINGS: FEATURES A REVERSIBLE MOTOR ALLOWING YOU TO SWITCH THE DIRECTION OF YOUR FANS ROTATION AND CREATE ENERGY SAVINGS
- More Info {7}:
- TECHNOLOGY: CORRELATED COLOR TEMPERATURE (CCT) SELECT TECHNOLOGY PROVIDES A SELECTION OF LIGHT COLORS RANGING FROM WARM WHITE BRIGHT LIGHT OR DAYLIGHT AND WIFI FANSYNC WHICH PROVIDES FAN CONTROL WITH A SMART DEVICE OR VOICE ASSISTANT
- More Info {8}:
- WARRANTY: LIMITED LIFETIME
- AIRFLOW EFFICIENCY LOW:
- 591
- AIRFLOW EFFICIENCY MEDIUM:
- 303
- AIRFLOW EFFICIENCY MEDIUM HIGH:
- 211
- AIRFLOW EFFICIENCY MEDIUM LOW:
- 474
- AIRFLOW EFFICIENCY MINI:
- 577
- AVG AIRFLOW EFFICIENCY:
- 173
- AVG CFM ENERGY:
- 3621
- AVG ENERGY USE:
- 21
- AVG ESTIMATED YEARLY ENERGY COST:
- 6
- AVG ESTIMATED YEARLY ENERGY COST ON HIGH:
- 9
- BLADE MATERIAL:
- COMPOSITE
- BLADE REVERSIBLE:
- NO
- BLADE SWEEP:
- 52
- BULB BASE:
- CONNECTOR PIN
- BULB CRI:
- 90
- CAP INCLUDED:
- YES
- CASE HEIGHT:
- 11.02''
- CASE LENGTH:
- 28.58
- CASE QUANTITY:
- 1
- CASE WEIGHT POUNDS:
- 17.97
- CASE WIDTH:
- 13.43''
- CEC UPLOADED:
- YES
- CEILING TO BLADE EDGE:
- 11.85
- CEILING TO BOTTOM (NO LIGHT KIT):
- 14.34
- CEILING TO BOTTOM (WITH LIGHT KIT):
- 14.8
- CFM LOW:
- 2304
- CFM MEDIUM:
- 3542
- CFM MEDIUM HIGH:
- 4430
- CFM MEDIUM LOW:
- 3083
- CFM MINI:
- 1557
- CURRENT DRAW HIGH:
- 0.42
- CURRENT DRAW LOW:
- 0.07
- CURRENT DRAW MEDIUM:
- 0.17
- CURRENT DRAW MEDIUM HIGH:
- 0.29
- CURRENT DRAW MEDIUM LOW:
- 0.11
- CURRENT DRAW MINI:
- 0.06
- DOE CLASSIFICATION:
- LSSD
- DOE-FTC UPLOADED:
- YES
- DOWNROD LENGTH:
- 6
- ENERGY EFFICIENT:
- YES
- EXEMPT FROM DOE PROCEDURE:
- NO
- FAN ENERGY STAR 4:
- NO
- HOUSING DIAMETER:
- 9.57
- INCLUDED CONTROL:
- TR361
- INCLUDED CONTROL TYPE:
- HANDHELD
- INDOOR:
- YES
- LEADWIRE:
- 14 MOTOR + 15 LIGHT
- LED:
- YES
- LIGHT KIT ENERGY STAR 4:
- NO
- LOCATION RATING:
- DAMP RATED
- MAX CEILING SLOPE:
- 27
- MAX WATTAGE:
- 30
- MAX WATTAGE 2:
- 12
- MOTOR REVERSIBLE:
- YES
- NUMBER OF BLADES:
- 5
- NUMBER OF SPEEDS:
- 6
- OUTDOOR:
- YES
- REGULATED PRODUCT:
- YES
- REVERSE SWITCH LOCATION:
- CONTROL
- RPM HIGH:
- 181
- RPM LOW:
- 76
- RPM MEDIUM:
- 130
- RPM MEDIUM HIGH:
- 155
- RPM MEDIUM LOW:
- 103
- RPM MINI:
- 50
- SAFETY RATING:
- UL APPROVED
- VOLTAGE CYCLES:
- 60 HZ
- WATTS HIGH:
- 31
- WATTS LOW:
- 4
- WATTS MEDIUM:
- 12
- WATTS MEDIUM HIGH:
- 21
- WATTS MEDIUM LOW:
- 7
- WATTS MINI:
- 3
- CEILING:
- YES
- HEIGHT:
- 14.80
- WIDTH:
- 52.00
- WIDTH RANGE:
- 50-55''
- IMAGE INFO:
- ''FPD8570BL.JPG:DEFAULT''
- FINISH:
- BLACK
- FPD8570BL_SS.PDF:
- CLICK HERE TO VIEW SPECIFICATION SHEET
- FPD8570BL_OM.PDF:
- CLICK HERE TO VIEW OWNERS MANUAL
- STANDARD STYLE:
- CEILING FANS WITH LIGHT
- OPTION3:
- PROP 65
- SHIP WEIGHT:
- 17.97
- BULB COLOR TEMP 2:
- 2700/3000/3500/4000/5000
- BULB CRI 2:
- 90
- BULB LUMENS 2:
- 1000
- NUMBER OF BULBS2:
- 1
- PROP 65:
- YES
- PROP 65 DESCRIPTION:
- THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING LEAD WHICH ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE INFORMATION GO TO WWW.P65WARNINGS.CA.GOV
- TYPE OF BULBS2:
- LED MODULE
