- AVAILABLE FOR PURCHASE:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 344
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- OPTION:
- ENERGY EFFICIENT
- OPTION1:
- OUTDOOR
- FAMILY:
- TRIAIRE CUSTOM
- AIR FLOW CFM:
- 6765
- AIR FLOW EFFICIENCY:
- 230
- BLADE PITCH:
- 14
- CANOPY:
- 5.75 DIA X 2.57 H
- HARMONIZED CODES:
- 8414.51.3000
- LENGTH:
- 44 48 52 56 60
- MAX WIDTH:
- 60''
- MOTOR SIZE:
- 158 X 22
- MOTOR TYPE:
- DC
- SHIP CARTON HEIGHT:
- 8.35''
- SHIP CARTON LENGTH:
- 15.94
- SHIP CARTON WIDTH:
- 8.86''
- SHIP WEIGHT:
- 12.88
- SOLD BY:
- EACH
- VOLTAGE:
- 120 V
- WARRANTY:
- LIMITED LIFETIME
- WEIGHT:
- 11.73
- More Info {1}:
- CONTROL: INCLUDES A WI-FI RECEIVER AND TR305 HANDHELD REMOTE WITH TWO 3V CR2032 BATTERIES - PUSH BUTTONS CONTROL 16 VARIABLE FAN SPEEDS.
- More Info {2}:
- INFINITE LIGHT LEVELS COLOR TEMPERATURE FAN/LIGHT TIMER POWERING ON/OFF AND FRESH AIR REVERSE HOME AWAY SAFE EXIT MODES
- More Info {3}:
- INSTALLATION: MOUNTS TO FLAT OR MINIMALLY SLOPED CEILINGS WITH THE INCLUDED 1-IN DIAMETER X 4.5-IN LENGTH DOWNROD - OPTIONAL DOWNRODS ARE AVAILABLE IN LENGTHS UP TO 72 INCHES TO ADJUST THE FANS HEIGHT TO 7FT - 9FT FROM THE FLOOR ENSURING ..''.
- More Info {4}:
- LIGHTING: 18-WATT DIMMABLE LED LIGHT KIT WITH CORRELATED COLOR TEMPERATURE (CCT) SELECT TECHNOLOGY AND OPAL FROSTED GLASS AVAILABLE FOR ADDED VERSATILITY (LIGHT KIT SOLD SEPARATELY)
- AIRFLOW EFFICIENCY LOW:
- 357
- AIRFLOW EFFICIENCY MEDIUM:
- 503
- AVG AIRFLOW EFFICIENCY:
- 247
- AVG CFM ENERGY:
- 4860
- AVG ENERGY USE WATTS:
- 20
- AVG ESTIMATED YEARLY ENERGY COST:
- 6
- AVG ESTIMATED YEARLY ENERGY COST ON HIGH:
- 8
- CANOPY DIAMETER:
- 5.75
- CANOPY HEIGHT:
- 2.57''
- CAP INCLUDED:
- YES
- CASE QUANTITY:
- 1
- CEC UPLOADED:
- YES
- CEILING TO BLADE EDGE:
- 12.92
- CEILING TO BOTTOM NO LK:
- 12.42
- CEILING TO BOTTOM WITH LK:
- 14.62
- CFM LOW:
- 821
- CFM MEDIUM:
- 4222
- COMPATIBLE ACCESSORIES:
- CCK8002MWW DR1-CPMW DR1SS-12MWW DR1SS-18MWW DR1SS-24MWW DR1SS-36MWW DR1SS-48MWW DR1SS-60MWW DR1SS-72MWW SCB1-52
- COMPATIBLE BLADES:
- BPW8514-44BLW BPW8514-44DWAW BPW8514-44MWW BPW8514-44SLW BPW8514-44WEW BPW8514-48BLW BPW8514-48DWAW BPW8514-48MWW BPW8514-48SLW BPW8514-48WEW BPW8514-52BLW BPW8514-52DWAW BPW8514-52MWW BPW8514-52SLW BPW8514-52WEW
- COMPATIBLE LIGHT KITS:
- LK8514MWM
- COMPATIBLE WALL CONTROLS:
- TW306
- CURRENT DRAW HIGH:
- 0.42
- CURRENT DRAW LOW:
- 0.04
- CURRENT DRAW MEDIUM:
- 0.13
- DOE CLASSIFICATION:
- LSSD
- DOEFTC UPLOADED:
- YES
- DOWNROD LENGTH:
- 4.5
- EXEMPT FROM DOE PROCEDURE:
- NO
- FAN ENERGY STAR:
- YES
- HOUSING DIAMETER:
- 7.09
- INCLUDED CONTROL:
- TR305
- INCLUDED CONTROL TYPE:
- HANDHELD
- LEADWIRE:
- 80
- MAX CEILING SLOPE:
- 27
- MAX WATT:
- 29
- MOTOR REVERSIBLE:
- YES
- NUMBER OF BLADES:
- 3
- NUMBER OF SPEEDS:
- 16
- REGULATED PRODUCT:
- YES
- REVERSE SWITCH LOCATION:
- CONTROL
- RPM HIGH (VI):
- 161
- RPM LOW (II):
- 28
- RPM MEDIUM (IV):
- 98
- SAFETY RATING:
- UL APPROVED CUL APPROVED
- VOLTAGE CYCLES:
- 60 HZ
- WATTS LOW:
- 2
- WATTS MEDIUM:
- 8
- WET RATED:
- YES
- CEILING:
- YES
- WALL:
- YES
- FINISH:
- WHITE
- IMAGE INFO:
- ''MAD8514MWM.JPG:DEFAULT''
- HEIGHT:
- 12.42
- WIDTH:
- 44.00
- WIDTH RANGE:
- 40-45''
- HTTPS:
- //WWW.DROPBOX.COM/S/40ULXJ4IH83VLTE/MAD8514MWM_SS.PDF:CLICK HERE TO VIEW SPEC SHEET DETAILS
- HTTPS1:
- //WWW.DROPBOX.COM/S/JN8Z9O9S5YDG32C/MAD8514MWM_OM.PDF:CLICK HERE TO VIEW MANUAL SHEET DETAILS
- STANDARD STYLE:
- CEILING FANS WITH LIGHT
- OPTION2:
- PROP 65
- LIGHT KIT INCLUDED:
- NO
- More Info {5}:
- LOCATION: THIS CEILING FAN IS WET RATED FOR USE IN INDOOR AND OUTDOOR SPACES MAKING IT IDEAL FOR ANY INDOOR ROOM OR SPACES LIKE GAZEBOS PATIOS PERGOLAS OR PORCHES
- More Info {6}:
- POWER: THE 16-SPEED QUIET AND ENERGY EFFICIENT DC MOTOR CAN PROVIDE AIRFLOW UP TO 6765 CFM
- More Info {7}:
- SAVINGS: FEATURES A REVERSIBLE MOTOR ALLOWING YOU TO SWITCH THE DIRECTION OF YOUR FAN?S ROTATION AND CREATE ENERGY SAVINGS
- More Info {8}:
- TECHNOLOGY: INCLUDES FANSYNC WI-FI CONNECTIVITY ALLOWING THE FAN TO PAIR WITH MOST SMART HOME DEVICES
- More Info {9}:
- WARRANTY: LIMITED LIFETIME
- CARTON CUBIC FEET:
- 0.68
- CASE HEIGHT:
- 8.35''
- CASE LENGTH:
- 15.94
- CASE WEIGHT POUNDS:
- 12.88
- CASE WIDTH:
- 8.86''
- CEILING TO BOTTOM (NO LIGHT KIT):
- 12.42
- CEILING TO BOTTOM (WITH LIGHT KIT):
- 14.62
- DOE-FTC UPLOADED:
- YES
- ENERGY EFFICIENT:
- YES
- INDOOR:
- YES
- LOCATION RATING:
- WET RATED
- MAX LENGTH:
- 60
- OUTDOOR:
- YES
- PROP 65:
- YES
- PROP 65 DESCRIPTION:
- THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING LEAD WHICH ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE INFORMATION GO TO WWW.P65WARNINGS.CA.GOV
- WATTS HIGH:
- 29
