- AVAILABLE FOR PURCHASE:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- UNKNOWN
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- OPTION:
- ENERGY STAR
- OPTION1:
- WET RATED
- FAMILY:
- TRIAIRE CUSTOM
- AIR FLOW CFM:
- 10387
- AIR FLOW EFFICIENCY:
- 342
- BLADE PITCH:
- 14
- CANOPY:
- 5.75 DIA 2.57 H
- HARMONIZED CODES:
- 8414.51.3000
- LENGTH:
- 64 72 84
- MAX WIDTH:
- 84''
- MOTOR SIZE:
- 153 X 25
- MOTOR TYPE:
- DC
- SHIP CARTON HEIGHT:
- 8.35''
- SHIP CARTON LENGTH:
- 15.94
- SHIP CARTON WIDTH:
- 8.86''
- SHIP WEIGHT:
- 15.08
- SOLD BY:
- EACH
- VOLTAGE:
- 120V
- WARRANTY:
- LIMITED LIFETIME
- WEIGHT:
- 13.67
- More Info {1}:
- 10387 CFM ON HIGH
- More Info {2}:
- COMPATIBLE WITH SMART HOME DEVICES USING THE WI-FI FANSYNC APP
- More Info {3}:
- DC MOTOR WITH REVERSE SWITCH VARIABLE SPEEDS LIGHT CONTROLS SLEEP TIMER HOME AWAY FRESH AIR AND SAFE EXIT FEATURES
- More Info {4}:
- TR305 HANDHELD REMOTE WITH 23A BATTERY INCLUDED
- AIRFLOW EFFICIENCY LOW:
- 723
- AIRFLOW EFFICIENCY MEDIUM:
- 757
- AVG AIRFLOW EFFICIENCY:
- 378
- AVG CFM ENERGY:
- 7827
- AVG ENERGY USE WATTS:
- 21
- AVG ESTIMATED YEARLY ENERGY COST:
- 6
- AVG ESTIMATED YEARLY ENERGY COST ON HIGH:
- 8
- CANOPY DIAMETER:
- 5.75
- CANOPY HEIGHT:
- 2.57''
- CAP INCLUDED:
- YES
- CASE QUANTITY:
- 1
- CEC UPLOADED:
- YES
- CEILING TO BLADE EDGE:
- 16.42
- CEILING TO BOTTOM NO LK:
- 15.92
- CEILING TO BOTTOM WITH LK:
- 18.12
- CFM LOW:
- 1734
- CFM MEDIUM:
- 6891
- COMPATIBLE ACCESSORIES:
- CCK8002MWW DR1-CPMW DR1SS-12MWW DR1SS-18MWW DR1SS-24MWW DR1SS-36MWW DR1SS-48MWW DR1SS-60MWW DR1SS-72MWW SCB1-52
- COMPATIBLE BLADES:
- BPW8515-64BLW BPW8515-64DWAW BPW8515-64MWW BPW8515-64SLW BPW8515-64WEW BPW8515-72BLW BPW8515-72DWAW BPW8515-72MWW BPW8515-72SLW BPW8515-72WEW BPW8515-84BLW BPW8515-84DWAW BPW8515-84MWW BPW8515-84SLW BPW8515-84WEW
- COMPATIBLE LIGHT KITS:
- LK8514MWM
- COMPATIBLE WALL CONTROLS:
- TW306
- CURRENT DRAW HIGH:
- 0.43
- CURRENT DRAW LOW:
- 0.05
- CURRENT DRAW MEDIUM:
- 0.14
- DOE CLASSIFICATION:
- LSSD
- DOEFTC UPLOADED:
- YES
- DOWNROD LENGTH:
- 8
- EXEMPT FROM DOE PROCEDURE:
- NO
- FAN ENERGY STAR:
- YES
- HOUSING DIAMETER:
- 7.09
- INCLUDED CONTROL:
- TR305
- INCLUDED CONTROL TYPE:
- HANDHELD
- LEADWIRE:
- 80
- MAX CEILING SLOPE:
- 27
- MAX WATT:
- 30
- MOTOR REVERSIBLE:
- YES
- NUMBER OF BLADES:
- 3
- NUMBER OF SPEEDS:
- 16
- REGULATED PRODUCT:
- YES
- REVERSE SWITCH LOCATION:
- CONTROL
- RPM HIGH (VI):
- 100
- RPM LOW (II):
- 28
- RPM MEDIUM (IV):
- 66
- SAFETY RATING:
- UL APPROVED CUL APPROVED
- VOLTAGE CYCLES:
- 60HZ
- WATTS LOW:
- 2
- WATTS MEDIUM:
- 9
- WET RATED:
- YES
- CEILING:
- YES
- WALL:
- YES
- FINISH:
- WHITE
- IMAGE INFO:
- ''''
- HEIGHT:
- 15.92
- HEIGHT RANGE:
- 15-20''
- WIDTH:
- 64.00
- WIDTH RANGE:
- 56'' AND OVER
