- AVAILABLE FOR PURCHASE:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 106
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- IMAGE INFO:
- ''MAD8514DZM.JPG:DEFAULT''
- FAMILY:
- TRIAIRE CUSTOM
- AIR FLOW CFM:
- 6795
- AIR FLOW EFFICIENCY:
- 252
- CANOPY:
- 5.75 DIA X 2.57 H
- HARMONIZED CODES:
- 8414.51.3000
- LIGHT KIT INCLUDED:
- NO
- MAX WIDTH:
- 60''
- MOTOR SIZE:
- 158 X 22
- MOTOR TYPE:
- DC
- SHIP CARTON HEIGHT:
- 8.35''
- SHIP CARTON LENGTH:
- 15.94
- SHIP CARTON WIDTH:
- 8.86''
- SHIP WEIGHT:
- 12.88
- SOLD BY:
- EA
- WEIGHT:
- 11.73
- More Info {1}:
- CONTROL: INCLUDES A TR360 HAND-HELD DC REMOTE WITH ONE 12V 23A BATTERY – PUSH BUTTONS CONTROL 6 FAN SPEEDS INFINITE LIGHT DIMMING WITH 5 CCT SELECT FAN REVERSING FRESH AIR MODE HOME AWAY MODE SAFE EXIT FEATURE AND POWERING ON/OFF.
- More Info {2}:
- FEATURES LEARN PAIRING TECHNOLOGY (NO DIP SWITCHES) AND COMES PRE-PAIRED WITH THE FAN FOR EASY SETUP.
- More Info {3}:
- IDEAL FOR ANY INTERIOR SPACE AS WELL AS FULLY EXPOSED OUTDOOR AREAS SUCH AS PATIOS PERGOLAS GAZEBOS AND PORCHES IT DELIVERS RELIABLE PERFORMANCE EVEN IN A WIDE RANGE OF OUTDOOR CONDITIONS.
- More Info {4}:
- INSTALLATION: MOUNTS TO FLAT OR MINIMALLY SLOPED CEILINGS WITH THE INCLUDED 1-IN DIAMETER X 4.5-IN LENGTH DOWNROD - OPTIONAL DOWNRODS ARE AVAILABLE IN LENGTHS UP TO 72 INCHES TO ADJUST THE FANS HEIGHT TO 7FT - 9FT FROM THE FLOOR ENSURING ..''.
- More Info {5}:
- IT ALSO ENABLES VOICE CONTROL THROUGH COMPATIBLE SMART HOME SYSTEMS LIKE ALEXA & GOOGLE ASSISTANT ALONG W/ CONVENIENT FEATURES SUCH AS SCHEDULING TIMERS HOME/AWAY MODE & GROUPING MULTIPLE FANS TOGETHER FOR SYNCHRONIZED CONTROL THROUGHO...
- More Info {6}:
- LIGHTING: COMPATIBLE WITH INTEGRATED 18-WATT DIMMABLE LED LIGHT KIT WITH CORRELATED COLOR TEMPERATURE (CCT) SELECT TECHNOLOGY AND OPAL FROSTED SHADE AVAILABLE FOR ADDED VERSATILITY (LIGHT KIT SOLD SEPARATELY)
- More Info {7}:
- LOCATION: WET RATED FOR USE IN BOTH INDOOR AND OUTDOOR ENVIRONMENTS THIS FAN IS ENGINEERED TO WITHSTAND DIRECT EXPOSURE TO RAIN WATER AND HIGH HUMIDITY.
- More Info {8}:
- POWER: THE 6-SPEED QUIET AND ENERGY EFFICIENT DC MOTOR CAN PROVIDE AIRFLOW UP TO 6765 CFM
- More Info {9}:
- SAVINGS: FEATURES A REVERSIBLE MOTOR THAT ALLOWS YOU TO CHANGE THE DIRECTION OF AIRFLOW SEASONALLY HELPING MAXIMIZE COMFORT THROUGHOUT THE YEAR WHILE SUPPORTING MORE EFFICIENT HEATING AND COOLING IN YOUR HOME.
- 10:
- TECHNOLOGY: FEATURES FANSYNC WI-FI CONNECTIVITY GIVING YOU FULL SMART CONTROL OF YOUR CEILING FAN FROM ANYWHERE.
- 11:
- WARRANTY: 1-YEAR FOR THE ORIGINAL PURCHASER. FOR ASSISTANCE CONTACT FANIMATION TECH SUPPORT AT 1-888-567-2055.
- 12:
- WITH THE FANSYNC APP YOU CAN ADJUST FAN SPEED TURN THE LIGHT ON/OFF DIM LIGHTING CHANGE COLOR TEMPERATURE (ON CCT MODELS) AND REVERSE AIRFLOW ALL FROM YOUR SMARTPHONE.
- AIRFLOW EFFICIENCY LOW:
- 694
- AIRFLOW EFFICIENCY MEDIUM:
- 443
- AIRFLOW EFFICIENCY MEDIUM HIGH:
- 329
- AIRFLOW EFFICIENCY MEDIUM LOW:
- 582
- AIRFLOW EFFICIENCY MINI:
- 657
- AVG AIRFLOW EFFICIENCY:
- 235
- AVG CFM ENERGY:
- 4551
- AVG ENERGY USE WATTS:
- 19
- AVG ESTIMATED YEARLY ENERGY COST:
- 5
- AVG ESTIMATED YEARLY ENERGY COST ON HIGH:
- 8
- CAP INCLUDED:
- NO
- CARTON CUBIC FEET:
- 0.68
- CASE HEIGHT:
- 8.35''
- CASE LENGTH:
- 15.94
- CASE QUANTITY:
- 1
- CASE WEIGHT POUNDS:
- 12.88
- CASE WIDTH:
- 8.86''
- CEC UPLOADED:
- YES
- CEILING TO BLADE EDGE:
- 12.92 14.13(BPW8565)
- CEILING TO BOTTOM:
- 14.62(LK8514)
- CEILING TO BOTTOM (NO LIGHT KIT):
- 12.42
- CFM LOW:
- 2983
- CFM MEDIUM:
- 4825
- CFM MEDIUM HIGH:
- 5736
- CFM MEDIUM LOW:
- 3903
- CFM MINI:
- 2009
- CURRENT DRAW HIGH:
- 0.39
- CURRENT DRAW LOW:
- 0.08
- CURRENT DRAW MEDIUM:
- 0.17
- CURRENT DRAW MEDIUM HIGH:
- 0.26
- CURRENT DRAW MEDIUM LOW:
- 0.11
- CURRENT DRAW MINI:
- 0.06
- DOE CLASSIFICATION:
- LSSD
- DOEFTC UPLOADED:
- YES
- DOWNROD LENGTH:
- 4.5
- EXEMPT FROM DOE PROCEDURE:
- NO
- FAN ENERGY STAR 4:
- NO
- HOUSING DIAMETER:
- 7.09
- INCLUDED CONTROL:
- TR360
- INCLUDED CONTROL TYPE:
- HANDHELD
- LEADWIRE:
- 14 MOTOR & 15 LIGHT
- LOCATION RATING:
- WET RATED
- MAX CEILING SLOPE:
- 27
- MAX LENGTH:
- 60
- MOTOR REVERSIBLE:
- YES
- NUMBER OF BLADES:
- 3
- NUMBER OF SPEEDS:
- 6
- PROP 65 DESCRIPTION:
- THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING LEAD WHICH ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE INFORMATION GO TO WWW.P65WARNINGS.CA.GOV
- REGULATED PRODUCT:
- YES
- REVERSE SWITCH LOCATION:
- CONTROL
- RPM HIGH:
- 164
- RPM LOW:
- 74
- RPM MEDIUM:
- 119
- RPM MEDIUM HIGH:
- 142
- RPM MEDIUM LOW:
- 97
- RPM MINI:
- 52
- SAFETY RATING:
- UL APPROVED
- VOLTAGE:
- 120 V
- VOLTAGE CYCLES:
- 60 HZ
- WARRANTY TYPE:
- 1 YEAR
- WATTS HIGH:
- 27
- WATTS LOW:
- 4
- WATTS MEDIUM:
- 11
- WATTS MEDIUM HIGH:
- 17
- WATTS MEDIUM LOW:
- 7
- WATTS MINI:
- 3
- CEILING:
- YES
- FINISH:
- BRONZE
- HEIGHT:
- 12.42
- WIDTH:
- 44.00
- WIDTH RANGE:
- 40-45''
