- AVAILABLE FOR PURCHASE:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 379
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- OPTION:
- ENERGY EFFICIENT
- OPTION1:
- OUTDOOR
- FAMILY:
- TRIAIRE CUSTOM
- VOLTAGE:
- 120 V
- AIR FLOW CFM:
- 10387
- AIR FLOW EFFICIENCY:
- 342
- BLADE PITCH:
- 14
- CANOPY:
- 5.75 DIA X 2.57 H
- HARMONIZED CODES:
- 8414.51.3000
- LIGHT KIT INCLUDED:
- NO
- MOTOR SIZE:
- 153 X 25
- MOTOR TYPE:
- DC
- SHIP CARTON HEIGHT:
- 8.35''
- SHIP CARTON LENGTH:
- 15.94
- SHIP CARTON WIDTH:
- 8.86''
- SHIP WEIGHT:
- 15.08
- SOLD BY:
- EA
- WARRANTY:
- 1 YEAR
- WEIGHT:
- 13.67
- More Info {1}:
- CONTROL: INCLUDES A WI-FI RECEIVER AND TR305 HANDHELD REMOTE W/ TWO 3V CR2032 BATTERIES-PUSH BUTTONS CONTROL 16 VARIABLE FAN SPEEDS INFINITE LIGHT LEVELS COLOR TEMPERATUREFAN/LIGHT TIMER POWERING ON/OFF& FRESH AIRREVERSEHOME AWAY S...
- More Info {2}:
- INSTALLATION: MOUNTS TO FLAT OR MINIMALLY SLOPED CEILINGS WITH THE INCLUDED 1-IN DIAMETER X 8-IN LENGTH DOWNROD - OPTIONAL DOWNRODS ARE AVAILABLE IN LENGTHS UP TO 72 INCHES TO ADJUST THE FANS HEIGHT TO 7FT - 9FT FROM THE FLOOR ENSURING MA..''.
- More Info {3}:
- IT ALSO ENABLES VOICE CONTROL THROUGH COMPATIBLE SMART HOME SYSTEMS LIKE ALEXA & GOOGLE ASSISTANT ALONG W/ CONVENIENT FEATURES SUCH AS SCHEDULING TIMERS HOME/AWAY MODE & GROUPING MULTIPLE FANS TOGETHER FOR SYNCHRONIZED CONTROL THROUGHO...
- More Info {4}:
- LIGHTING: 18-WATT DIMMABLE LED LIGHT KIT WITH CORRELATED COLOR TEMPERATURE (CCT) SELECT TECHNOLOGY AND OPAL FROSTED GLASS AVAILABLE FOR ADDED VERSATILITY (LIGHT KIT SOLD SEPARATELY)
- More Info {5}:
- LOCATION: THIS CEILING FAN IS WET RATED FOR USE IN INDOOR AND OUTDOOR SPACES MAKING IT IDEAL FOR ANY INDOOR ROOM OR SPACES LIKE GAZEBOS PATIOS PERGOLAS OR PORCHES
- More Info {6}:
- POWER: THE 16-SPEED QUIET AND ENERGY EFFICIENT DC MOTOR CAN PROVIDE AIRFLOW UP TO 10387 CFM
- More Info {7}:
- SAVINGS: FEATURES A REVERSIBLE MOTOR THAT ALLOWS YOU TO CHANGE THE DIRECTION OF AIRFLOW SEASONALLY HELPING MAXIMIZE COMFORT THROUGHOUT THE YEAR WHILE SUPPORTING MORE EFFICIENT HEATING AND COOLING IN YOUR HOME.
- More Info {8}:
- TECHNOLOGY: FEATURES FANSYNC WI-FI CONNECTIVITY GIVING YOU FULL SMART CONTROL OF YOUR CEILING FAN FROM ANYWHERE.
- More Info {9}:
- WARRANTY: 1-YEAR FOR THE ORIGINAL PURCHASER. FOR ASSISTANCE CONTACT FANIMATION TECH SUPPORT AT 1-888-567-2055.
- AIRFLOW EFFICIENCY LOW:
- 723
- AIRFLOW EFFICIENCY MEDIUM:
- 757
- AVG AIRFLOW EFFICIENCY:
- 378
- AVG CFM ENERGY:
- 7827
- AVG ENERGY USE:
- 21
- AVG ESTIMATED YEARLY ENERGY COST:
- 6
- AVG ESTIMATED YEARLY ENERGY COST ON HIGH:
- 8
- CAP INCLUDED:
- NO
- CARTON CUBIC FEET:
- 0.68
- CASE HEIGHT:
- 8.35''
- CASE LENGTH:
- 15.94
- CASE QUANTITY:
- 1
- CASE WEIGHT POUNDS:
- 15.08
- CASE WIDTH:
- 8.86''
- CEC UPLOADED:
- YES
- CEILING TO BLADE EDGE:
- 16.42
- CEILING TO BOTTOM:
- 18.12(LK8514) 19.43(LK8505)
- CEILING TO BOTTOM (WITH LIGHT KIT):
- 18.12
- CFM LOW:
- 1734
- CFM MEDIUM:
- 6891
- CURRENT DRAW HIGH:
- 0.43
- CURRENT DRAW LOW:
- 0.05
- CURRENT DRAW MEDIUM:
- 0.14
- DOE CLASSIFICATION:
- LSSD
- DOE-FTC UPLOADED:
- YES
- DOWNROD LENGTH:
- 8
- ENERGY EFFICIENT:
- YES
- EXEMPT FROM DOE PROCEDURE:
- NO
- FAN ENERGY STAR 4:
- NO
- HOUSING DIAMETER:
- 7.09
- INCLUDED CONTROL:
- TR305
- INCLUDED CONTROL TYPE:
- HANDHELD
- INDOOR:
- YES
- LEADWIRE:
- 80
- LOCATION RATING:
- DAMP RATED
- MAX CEILING SLOPE:
- 27
- MAX LENGTH:
- 84
- MAX WIDTH:
- 84''
- MOTOR REVERSIBLE:
- YES
- NUMBER OF BLADES:
- 3
- NUMBER OF SPEEDS:
- 16
- OUTDOOR:
- YES
- REGULATED PRODUCT:
- YES
- REVERSE SWITCH LOCATION:
- CONTROL
- RPM HIGH:
- 100
- RPM LOW:
- 28
- RPM MEDIUM:
- 66
- SAFETY RATING:
- UL APPROVED
- VOLTAGE CYCLES:
- 60 HZ
- WATTS HIGH:
- 30
- WATTS LOW:
- 2
- WATTS MEDIUM:
- 9
- CEILING:
- YES
- HEIGHT:
- 15.92
- HEIGHT RANGE:
- 15-20''
- WIDTH:
- 64.00
- WIDTH RANGE:
- 56'' AND OVER
- IMAGE INFO:
- ''MAD8515BS.JPG:DEFAULT''
- FINISH:
- BRASS
- MAD8515BS_SS.PDF:
- CLICK HERE TO VIEW SPECIFICATION SHEET
- MAD8515BS_CW_OM.PDF:
- CLICK HERE TO VIEW OWNERS MANUAL
- STANDARD STYLE:
- CEILING FANS
- OPTION2:
- PROP 65
- PROP 65:
- YES
- PROP 65 DESCRIPTION:
- THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING LEAD WHICH ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE INFORMATION GO TO WWW.P65WARNINGS.CA.GOV
- 10:
- WITH THE FANSYNC APP YOU CAN ADJUST FAN SPEED TURN THE LIGHT ON/OFF DIM LIGHTING CHANGE COLOR TEMPERATURE (ON CCT MODELS) AND REVERSE AIRFLOW ALL FROM YOUR SMARTPHONE.
- AVG ENERGY USE WATTS:
- 21
- DOEFTC UPLOADED:
- YES
- WARRANTY TYPE:
- 1 YEAR
- CEILING TO BOTTOM (NO LIGHT KIT):
- 15.92
