- AVAILABLE FOR PURCHASE:
- NO
- QUANTITY AVAILABLE AT MANUFACTURER:
- 0
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- IMAGE INFO:
- ''FPD6658MW.JPG:DEFAULT''
- FAMILY:
- YOGI
- AIR FLOW CFM:
- 4721
- AIR FLOW EFFICIENCY:
- 177
- BLADE PITCH:
- VARIED
- BLADE SPAN:
- 52
- CANOPY:
- 8.76 DIA X 2.52 H
- HARMONIZED CODES:
- 8414.51.3000
- LIGHT KIT INCLUDED:
- NO
- MOTOR SIZE:
- 125 X 20
- MOTOR TYPE:
- DC
- SHIP CARTON HEIGHT:
- 9.45''
- SHIP CARTON LENGTH:
- 35.67
- SHIP CARTON WIDTH:
- 10.87''
- SHIP WEIGHT:
- 15.44
- SOLD BY:
- EA
- WEIGHT:
- 12.13
- More Info {1}:
- ALSO INCLUDES WI-FI FANSYNC CONNECTIVITY ALLOWING CONTROL OF THE FAN AND LIGHT THROUGH A COMPATIBLE SMART DEVICE OR VOICE ASSISTANT.
- More Info {2}:
- CONTROL: INCLUDES A TR360 HAND-HELD REMOTE WITH TWO 1.5V AAA ALKALINE BATTERIES – PUSH BUTTONS CONTROL 6 FAN SPEEDS INFINITE LIGHT DIMMING WITH 5 CCT SELECT FAN REVERSING FRESH AIR MODE HOME AWAY MODE SAFE EXIT FEATURE AND POWERING O...
- More Info {3}:
- FEATURES LEARN PAIRING TECHNOLOGY (NO DIP SWITCHES) AND COMES PRE-PAIRED WITH THE FAN FOR EASY SETUP.
- More Info {4}:
- INSTALLATION: MOUNTS TO FLAT OR MINIMALLY SLOPED CEILINGS WITH THE INCLUDED 1-IN DIAMETER X 6-IN LENGTH DOWNROD - OPTIONAL DOWNRODS ARE AVAILABLE IN LENGTHS UP TO 72 INCHES TO ADJUST THE FANS HEIGHT TO 7FT - 9FT FROM THE FLOOR ENSURING MA..''.
- More Info {5}:
- IT ALSO ENABLES VOICE CONTROL THROUGH COMPATIBLE SMART HOME SYSTEMS LIKE ALEXA & GOOGLE ASSISTANT ALONG W/ CONVENIENT FEATURES SUCH AS SCHEDULING TIMERS HOME/AWAY MODE & GROUPING MULTIPLE FANS TOGETHER FOR SYNCHRONIZED CONTROL THROUGHO...
- More Info {6}:
- IT PERFORMS RELIABLY IN ENVIRONMENTS EXPOSED TO HUMIDITY BUT SHOULD NOT BE DIRECTLY EXPOSED TO RAIN OR WATER.
- More Info {7}:
- LIGHTING: LIGHT KIT NOT INCLUDED
- More Info {8}:
- LOCATION: DAMP RATED FOR USE IN BOTH INDOOR AND OUTDOOR COVERED SPACES THIS FAN IS DESIGNED TO WITHSTAND MOISTURE AND HUMIDITY MAKING IT IDEAL FOR AREAS SUCH AS COVERED PATIOS PORCHES SUNROOMS BATHROOMS AND LAUNDRY ROOMS.
- More Info {9}:
- POWER: THE 6-SPEED QUIET AND ENERGY EFFICIENT DC MOTOR PROVIDES AIRFLOW UP TO 4721 CFM
- 10:
- SAVINGS: FEATURES A REVERSIBLE MOTOR THAT ALLOWS YOU TO CHANGE THE DIRECTION OF AIRFLOW SEASONALLY HELPING MAXIMIZE COMFORT THROUGHOUT THE YEAR WHILE SUPPORTING MORE EFFICIENT HEATING AND COOLING IN YOUR HOME.
- 11:
- TECHNOLOGY: FEATURES FANSYNC WI-FI CONNECTIVITY GIVING YOU FULL SMART CONTROL OF YOUR CEILING FAN FROM ANYWHERE.
- 12:
- WARRANTY: 1-YEAR FOR THE ORIGINAL PURCHASER. FOR ASSISTANCE CONTACT FANIMATION TECH SUPPORT AT 1-888-567-2055.
- 13:
- WITH THE FANSYNC APP YOU CAN ADJUST FAN SPEED TURN THE LIGHT ON/OFF DIM LIGHTING CHANGE COLOR TEMPERATURE (ON CCT MODELS) AND REVERSE AIRFLOW ALL FROM YOUR SMARTPHONE.
- AIRFLOW EFFICIENCY LOW:
- 520
- AIRFLOW EFFICIENCY MEDIUM:
- 386
- AIRFLOW EFFICIENCY MEDIUM HIGH:
- 269
- AIRFLOW EFFICIENCY MEDIUM LOW:
- 472
- AIRFLOW EFFICIENCY MINI:
- 490
- AVG AIRFLOW EFFICIENCY:
- 168
- AVG CFM ENERGY:
- 3108
- AVG ENERGY USE WATTS:
- 18
- AVG ESTIMATED YEARLY ENERGY COST:
- 5
- AVG ESTIMATED YEARLY ENERGY COST ON HIGH:
- 8
- BLADE MATERIAL:
- COMPOSITE
- BLADE REVERSIBLE:
- NO
- CAP INCLUDED:
- NO
- CARTON CUBIC FEET:
- 2.12
- CASE HEIGHT:
- 9.45''
- CASE LENGTH:
- 35.67
- CASE QUANTITY:
- 1
- CASE WEIGHT POUNDS:
- 15.44
- CASE WIDTH:
- 10.87''
- CEC UPLOADED:
- YES
- CEILING TO BLADE EDGE:
- 12.68
- CEILING TO BOTTOM (NO LIGHT KIT):
- 12.68
- CFM LOW:
- 1923
- CFM MEDIUM:
- 3431
- CFM MEDIUM HIGH:
- 4146
- CFM MEDIUM LOW:
- 2693
- CFM MINI:
- 1279
- CURRENT DRAW HIGH:
- 0.38
- CURRENT DRAW LOW:
- 0.07
- CURRENT DRAW MEDIUM:
- 0.14
- CURRENT DRAW MEDIUM HIGH:
- 0.23
- CURRENT DRAW MEDIUM LOW:
- 0.09
- CURRENT DRAW MINI:
- 0.05
- DOE CLASSIFICATION:
- LSSD
- DOEFTC UPLOADED:
- YES
- DOWNROD LENGTH:
- 6
- EXEMPT FROM DOE PROCEDURE:
- NO
- FAN ENERGY STAR 4:
- NO
- HOUSING DIAMETER:
- 9.5
- INCLUDED CONTROL:
- TR360
- INCLUDED CONTROL TYPE:
- HANDHELD
- LEADWIRE:
- 14
- LOCATION RATING:
- DAMP RATED
- MAX CEILING SLOPE:
- 27
- MOTOR REVERSIBLE:
- YES
- NUMBER OF BLADES:
- 3
- NUMBER OF SPEEDS:
- 6
- PROP 65 DESCRIPTION:
- THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING LEAD WHICH ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE INFORMATION GO TO WWW.P65WARNINGS.CA.GOV
- REGULATED PRODUCT:
- YES
- REVERSE SWITCH LOCATION:
- CONTROL
- RPM HIGH:
- 150
- RPM LOW:
- 70
- RPM MEDIUM:
- 109
- RPM MEDIUM HIGH:
- 128
- RPM MEDIUM LOW:
- 89
- RPM MINI:
- 48
- SAFETY RATING:
- UL APPROVED
- VOLTAGE:
- 120 V
- VOLTAGE CYCLES:
- 60 HZ
- WARRANTY TYPE:
- 1 YEAR
- WATTS HIGH:
- 27
- WATTS LOW:
- 4
- WATTS MEDIUM:
- 9
- WATTS MEDIUM HIGH:
- 15
- WATTS MEDIUM LOW:
- 6
- WATTS MINI:
- 3
- CEILING:
- YES
- FINISH:
- WHITE
- HEIGHT:
- 12.68
- WIDTH:
- 52.00
- WIDTH RANGE:
- 50-55''
